Description

Installation information:

The system is specifically designed to control electric gates, garage doors and barriers. The device is only suitable for controlling a gate equipped with an electric motor and engine control unit. The device requires a mini-SIM card. Note to end users: Contact a gate installer to install the device!

Main features:

Control of relays with free phone call Sending SMS upon state change of the 4 contact inputs Programmable through USB, SMS or via Internet Large event memory Supported operating system: Windows 10

Characteristics of Gate Control:

Control of the opening and closing of automated gates and barriers via free GSM call, using caller identification

SMS notification on the malfunctions of the gate:

– blocking of the photocell

– forced opening of the barrier housing

– barrier arm or gate jam Control (opening / closing) can only be initiated from authorized phone numbers preconfigured in the device or, depending on the settings, from any phone number, without limitations Selectable control mode, depending on gate type

Advantages in comparison with radio control:

Control from mobile phone without any additional unit

No radio interference, no accidentally opened gate Possibility of registering up to 1000 users with permission granting (e.g. entry prohibition out of labor hours)

Stores last 1200 events with identification of users and opening time

Event log can be downloaded remotely (via Internet), printed or stored electronically

Sends notification in SMS and logs if the gate remains open or the photocell is blocked There is no distance limit for control
